DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual

6-38

6.7

Setting a Real-time Clock

After you connect an DVP-ES3/EX3/SV3/SX3 Series CPU module to a computer, you can set the real-time

clock in the CPU module through ISPSoft/DIADesigner.



ISPSoft

(1) On the

Tools

menu, click

Set RTC

(2) Select

Computer

, and then click

Synchronize

to complete setting the real time clock.

(3) RTC setting is complete.
