Chapter 1 Product Introduction
1-3
1.1.1 DVP-ES3/EX3 Series CPU Modules and Their Extension Modules
Classification Model Name Description
DVP-ES3
Series CPU
module
DVP32ES311T
24 VDC powered CPU module
Transistor, NPN output (sinking), 1x Ethernet port, 2x RS-485 ports, 1x
USB & CAN port, 1x Micro SD interface, supporting 32 I/Os (16 DI +
16 DO) and up to 256 I/Os. Program capacity: 64K steps, removable
terminal blocks
DVP32ES300T
100-240 VAC powered CPU module
Transistor, NPN output (sinking), 1x Ethernet port, 2x RS-485 ports, 1x
USB & CAN port, 1x Micro SD interface, supporting 32 I/Os (16 DI +
16 DO) and up to 256 I/Os. Program capacity: 64K steps, removable
terminal blocks
DVP32ES300R
100-240 VAC powered CPU module
Relay output, 1x Ethernet port, 2x RS-485 ports, 1x USB & CAN port,
1x Micro SD interface, supporting 32 I/Os (16 DI+16 DO) and up to
256 I/Os. Program capacity: 64K steps, removable terminal blocks
DVP48ES300T
100-240 VAC powered CPU module
Transistor, NPN output (sinking), 1x Ethernet port, 2x RS-485 ports, 1x
USB & CAN port, 1x Micro SD interface, supporting 48 I/Os (24 DI +
24 DO) and up to 256 I/Os. Program capacity: 64K steps, removable
terminal blocks
DVP48ES300R
100-240 VAC powered CPU module
Relay output, 1x Ethernet port, 2x RS-485 ports, 1x USB & CAN port,
1x Micro SD interface, supporting 48 I/Os (24 DI + 24 DO) and up to
256 I/Os. Program capacity: 64K steps, removable terminal blocks
DVP64ES300T
100-240 VAC powered CPU module
NPN output, 1x Ethernet port, 2x RS-485 ports, 1x USB & CAN port,
1x Micro SD interface, supporting 64 I/Os (32 DI + 32 DO) and up to
256 I/Os. Program capacity: 64K steps, removable terminal blocks
DVP64ES300R
100-240 VAC powered CPU module
Relay output, 1x Ethernet port, 2x RS-485 ports, 1x USB & CAN port,
1x Micro SD interface, supporting 64 I/Os (32 DI + 32 DO) and up to
256 I/Os. Program capacity: 64K steps, removable terminal blocks
