Chapter 2 Specifications and System Configuration
2-5
2.1.2.2 Electrical specifications
DVP32ES311T
24 VDC (20.4 VDC–28.8 VDC) (-15% to +20%)
Communication
port isolation
USB, COM1, COM2, and Ethernet ports: 500 VAC
Model
DVPxxES300R/T, DVP32ES300TEC, DVPxxEX300R/T, DVP28EX300MT
100 ~ 240VAC (-15% ~ 10%), 50 / 60Hz ± 5%
70 VA
MAX
500mA
DC24Voutput with short-circuit protection
Over voltage
OVC II
Surge voltage
3,000 VAC (Primary-secondary), 3,000 VAC (Primary-FE), 500 VAC (Secondary-FE)
Insulation
impedance
≧5
MΩ
(the isolation between each input/output point and the ground should be 500 VAC）
Grounding
The
diameter of the ground should not be less than the diameters of the cables connected
to the terminals L and N. If using multiple pieces of PLC, use a single-point ground.
Communication
port isolation
USB, COM1, COM2, Ethernet, EtherCAT (applicable to DVP32ES300TEC) ports:
Weight
Model
Model
