Chapter 7 Memory Card
7.4
Memory Card Contents
7.4.1
Initializing a Memory Card
When you insert an SDHC card into a CPU module that is powered on, and use ISPSoft / DIADesigner ->
CARD Utility to back up a project, the system initializes the SDHC card, and creates a default folder named
according to the model of the CPU module. (If the folder is already existed, the system does not create a
second folder for the same model.)
When the system initializes an SDHC card, it automatically adds any missing folders to the directory structure.
However, if the initialization of a SDHC card fails, you cannot initialize the SDHC card again until you reformat it.
When you initialize a memory card, the SYSTEM indicator in the software blinks.
7.4.2
Folder Structure in a Memory Card
The image below shows the default folder group created by a DVP-ES3/EX3/SV3/SX3 System. The folder
name is ES3. Several subfolders are contained inside the ES3 folder. Related files created by you and the
DVP-ES3/EX3/SV3/SX3 system are stored in the subfolders.
PLC CARD
Log
To Next Page
