DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
9-12
_9
9.3.2 EtherNet/IP Specification
Item DVP-ES3/EX3/SV3/SX3 Series
General
Device type Scanner / Adapter
Topology type Star topology or linear topology (DVP-EX3)
Periodic I/O
Connection
CIP connection number
(for a data exchange table)
16 8
TCP connection number
8
(for all connection types)
Requested Packet Interval (RPI) 5 ms – 1000 ms
Max. Transmission Speed 3000 pps
Max. Data Length/per
transmission
500 bytes
Supported devices D/M D/X/Y/SR
Non-periodic
Explicit Message
Class 3
(Connected Type)
8 8
UCMM
(Non-Connected Type, only uses
TCP connections)
Total 8
(for all connection types)
CIP Objects
Identity, Message Router, Assembly, Connection
Manager, Port, TCP/IP interface, Ethernet link,
Vendor specific
CIP Network TAG
Max. Consumed TAG Number 16
Max. Produced TAG Number 16
Max. Data Length
500 bytes (IO Connection)
400 bytes (Explicit Message)
Requested Packet Interval (RPI) 5 ms – 1000 ms
Maximum number of connections when using DVP-ES3/EX3/SV3/SX3 Series to connect to other devices through
Ethernet/IP:
 When DVP-ES3 Series PLC CPU acts as a Scanner, it can connected up to 8 devices. Each device can establish
up to 16 connections for data mapping. Data mapping types can be I/O connection and Consumed TAG. You can
use explicit message for data mapping at the same time, up to 8 explicit message connections can be created.
 When DVP-ES3/EX3/SV3/SX3 Series PLC CPU acts as a Adapter, it can connected up to 8 devices. Each device
can establish up to 8 connections for data mapping. Data mapping types can be I/O connection and Consumed
TAG. You can use explicit message for data mapping at the same time, up to 8 explicit message connections can
