DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
9-14
_9
9.4 EIP Builder
The Delta EtherNet/IP software, EIP Builder, is embedded in ISPSoft. You run it from the ISPSoft software (version 3.0
or later). Download the ISPSoft software at:
http://www.deltaww.com/services/DownloadCenter2.aspx?secID=8&pid=2&tid=0&CID=06&itemID=060301&typeID=1&d
ownloadID=,&title=--%20Select%20Product%20Series%20--&dataType=8;&check=1&hl=en-US
9.4.1 Run the EIP Builder
You can call EIP Builder from Delta EIP Scanner’s HWCONFIG in ISPSoft. You can also call it independently to set up
parameters for the Adapter. The Delta EIP Scanner is equipped with the EtherNet/IP communication PLC and the
EtherNet/IP module. Refer to Section 9.9.3 for a list of Delta EIP Scanner products supported by EIP Builder.
9.4.1.1 Run the EIP Builder via an EIP Scanner
 Steps to run EIP Builder
Run EIP Builder from an EIP Scanner product.
Open
ISPSoft V3 0.
Create
ISPSoft Project
Open
HWCONFIG
Download
HWCONFIG
Open
EIP Builder
Start
1. Open ISPSoft V3.0: click the Start menu and go to Programs > Delta Industrial Automation > ISPSoft
2. Create a new project: on the File menu, click New to display the Create a New Project dialog box.
