Delta DVP-ES3 Series Hardware Manual

Chapter 2 Specifications and System Configuration
2-21
2_
2.2.2.2 Electrical specifications
Model
Item
DVP28SV
311T
DVP28SV
311R
DVP28SV
311S
DVP20SX
311T
DVP20SX
311R
DVP20SX
311S
Supply voltage
24 VDC (20.4 VDC–28.8 VDC) (-15% to +20%)
Fuse capacity
4 A / 30 VDC
Power
consumption
4 W 4.5 W 4 W 5 W 5.5 W 5 W
Protection
24 VDC output with short-circuit protection
Surge voltage
protection
0.5 KV
Grounding
1. G
rounding spring should be used under rail grounding.
2.
The wire diameter of the power supply grounding wiring shall not be smaller than that
of the 24V and 0V wire diameter at the power supply end.
Communication
port isolation
Coupling voltag: 1 KV
Weight (g)
249.4 g
278.9 g
249 g
253.9 g
270 g
255.5 g
 Electrical specifications for the inputs on DVP-SV3/SX3 Series PLC CPU. The signals passing
through the inputs are 24 VDC signals.
Model
Item
DVP28SV311T
DVP28SV311R
DVP28SV311S
DVP20SX311T
DVP20SX311R
DVP20SX311S
Number of inputs
16 (X0 ~ X17)
8 (X0 ~ X7)
Connector type
Removable terminal blocks
Input type
Digital input
Input form
Direct current (sinking or sourcing)
Input voltage/ current
24 VDC, 5 mA
Action
level
OFF→ON >15 VDC
ON→OFF
<5 VDC
Response
time
OFF→ON
X0~X7：
< 2.5 μs
X10~X17：< 50 μs
ON→OFF
X0~X7
：
< 2.5 μs
X10~X17：< 50 μs
Maximum input
frequency
X0 ~ X7: 200 kHz
X10 ~ X17: 10 kHz
Input impedance
4.7 kΩ
Input isolation
Coupling voltage: 1 KV
Input display
When the optocoupler is driven, the input LED indicator is ON.
Analog input channels
N/A
4
Analog input
conversion
time*
1
N/A 3 ms / channel
Analog input
resolution
N/A 12 bits
