Delta DVP-ES3 Series Hardware Manual

DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
2-4
_2
Item
DVP32ES311T, DVPxxES300R/T,
DVP32ES300TEC, DVPxxEX300R/T,
DVP28EX300MT
Remark
Special data register [SR]
2048 (SR0–SR2047)
Serial communication port
2x RS-485
Ethernet port
10/100 M; ES3 Series: single port; EX3 Series: two
ports; supporting Modbus TCP and Ethernet/IP
Adapter protocols
Refer to the section
9.3 for more details on
Ethernet
specificaitons
USB port
Mini B type USB
Storage interface
SD Card (Micro SD); maximum storage: 32G
Real-time clock
Years, months, days, hours, minutes, seconds and
weeks
The accuracy
Environment
Cold Normal Hot
0°C
/32°F
25°C
/77°F
55°C
/131°F
Deviation
(seconds per
month)
-117 52 -132
Active about one
week, storing in an
electric double layer
capacitor
CANopen DS301 (Master) Maximum node: 64; maximum bytes: 2000
Built-in CAN
communication port
(except
DVP32ES300TEC)
CANopen DS301 (Slave) Maximum PDO: 8; maximum bytes: 8
EtherCAT communication
port
Supports EtherCAT Master 8 axes point-to-point
positioning control; transmission rate: 100Mbps
Note: only Delta servos ASDA-A2-E, ASDA-A3-E,
ASDA-B3-E and Delta inverters C2000 and
CH2000
are supported.
Only applicable to
DVP32ES300TEC
