Epson SC-T7000 series User Manual

SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT Overview 200
Confidential
CR related
parts/units
CR TIMING BELT
Replacement
1
---
p. 139
After
replacement
2
Turn the power on in normal mode. --- √√
3
CR Belt Tension Check √
Tensimeter
U-507
√√
p. 234
4
APG function check √√---
p. 237
5
CR Scale Check √√---
p. 239
6
CR Active Damper Adjustment (Automatic) √√---
p. 240
7
Ink Mark Sensor check & auto adjustment √
PGPP
√ ---
p. 238
8
Auto Uni-d adjustment √
PGPP
√ ---
p. 241
9
Auto Bi-D adjustment, acceleration and
deceleration correction
√
PGPP
√ ---
p. 242
10
PW + T&B&S check and adjustment √
Matte paper
√ ---
p. 243
11
Housing Assembly --- √√
CR UNIT (CR Assy)
Replacement
1
---
p. 156
After
replacement
2
CR Belt Tension Check √
Tensimeter
U-507
√√
p. 234
3
APG function check √√√
p. 237
4
CR Scale Check √√√
p. 239
5
CR Active Damper Adjustment (Automatic) √√---
p. 240
6
Head inclination auto adjustment (CR
direction)
√√---
p. 253
7
Head slant auto adjustment (PF direction) √√---
p. 256
8
Head inclination manual adjustment (CR
direction)
√√---
p. 254
9
Head slant manual adjustment (PF direction) √√---
p. 257
10
PG Adjustment √
Thickness gauge
√ ---
p. 245
11
Ink Mark Sensor check & auto adjustment √
PGPP
√ ---
p. 238
12
Auto Uni-d adjustment √
PGPP
√ ---
p. 241
13
Auto Bi-D adjustment, acceleration and
deceleration correction
√
PGPP
√ ---
p. 242
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired (Reattached)
Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
