SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 93
Confidential
3.4.2.7 PRINTER COVER
1. Disengage the three hinges of the PRINTER COVER from the bearings, and
remove the PRINTER COVER.
Figure 3-20. Removing the PRINTER COVER
Bearing
Hinge
PRINTER COVER
