SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT CR Related Adjustments 243
Confidential
4.10.8 PW + T&B&S check and adjustment
4.10.8.1 PW Adjustment
PAPER USED
Type: Archival Matte Paper/Enhanced Matte Paper
Size: A4
EXECUTION MODE
Normal mode
PROCEDURE
1. Turn the printer ON.
2. Load the paper into the printer.
3. Start the Service Program and select PW + T&B&S check and adjustment.
4. Click [PW Adjustment]. Check the displayed message.
When the adjustment is complete normally: Go to Step 6
Data written in NVRAM and acquired data have mismatch. Please try again.:
Go to Step 4
Failed adjustment. Check printer condition.: Go to Step 5
5. Since the PW sensor may not be attached properly, attach it again properly. (P.
161) After attachment, check it again performing Step 4. If the same error still
occurs after the recheck, check if the sensor operates properly or not carrying out
Sensor check (P. 279). If any error was found by carrying out Sensor check,
replace the PW sensor.
6. Click [Finish].
7. Turn the printer OFF to finish the adjustment.
4.10.8.2 T&B&S Adjustment
PAPER USED
Type: Archival Matte Paper/Enhanced Matte Paper
Size: A4
STANDARD VALUE
Top margin: 10 ± 0.4 mm
Bottom margin: 14 ± 0.6 mm
Side margin: 10 ± 0.4 mm
PROCEDURE
1. Turn the printer ON.
2. Load the paper into the printer.
3. Start the Service Program and select PW + T&B&S check and adjustment.
4. Click [Print]. The adjustment pattern will be printed.
5. Measure the distance for the positions shown in Figure 4-30.
Within the standards: Go to Step 9
Out of the standards: Go to Step 4
C A U T I O N
Make sure to place the adjustment pattern on a flat place to
measure the distances.
To Next Page
