Epson SC-T7000 series User Manual

SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
APPENDIX Part names used in this manual 313
Confidential
Electric Circuit
Components
MAIN BOARD BOARD ASSY.,MAIN 3.4.3.1
MAIN-B BOARD BOARD ASSY.,MAIN 3.4.3.2
MAIN-C BOARD BOARD ASSY.,MAIN 3.4.3.3
SUB BOARD BOARD ASSY.,SUB 3.4.3.4
SUB-B BOARD BOARD ASSY.,SUB 3.4.3.5
PSH BOARD
BOARD ASSY.,POWER
SUPPLY
3.4.3.6
PANEL BOARD
 PANEL,ASSY.,ESL,ASP
 HOUSING,PANEL,LOWER,
ASSY,ASP
3.4.3.7
Carriage Mechanism/
Ink System
Mechanism
CR COVER COVER,CR 3.4.4.1
DAMPER KIT DUCT ASSY.,CR,ASP 3.4.4.2
PRINT HEAD PRINT HEAD,IC856V 3.4.4.3
HEAD FFC HARNESS 3.4.4.4
CR FFC HARNESS 3.4.4.5
CR SCALE SCALE,CR,44;ASP 3.4.4.6
CR ENCODER BOARD ASSY.,ENCODER 3.4.4.7
CR TIMMING BELT TIMING BELT,CR,44 3.4.4.8
CR MOTOR MOTOR ASSY.,CR 3.4.4.9
CR HP SENSOR PHOTO INTERRUPTER 3.4.4.10
APG UNIT
 MOTOR,APG,ASSY.,ESL,A
SP
 MOTOR ASSY.,ASF,SUB
3.4.4.11
PG SENSOR PHOTO INTERRUPTER 3.4.4.12
PUMP CAP UNIT PUMP CAP ASSY,ASP 3.4.4.13
IC HOLDER HOLDER ASSY.,IC,ASP 3.4.4.14
INK TUBE TUBE,CR,44,ASSY.,ESL,ASP 3.4.4.15
CR UNIT CR,44,ASSY.,ESL,ASP 3.4.4.16
IM SENSOR BOARD ASSY.,INK MARK 3.4.4.17
PW SENSOR
BOARD
ASSY.,DETECTOR,PW;B
3.4.4.18
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3 sec.No.)
Paper Feed
Mechanism
PF MOTOR MOTOR ASSY.,PF 3.4.5.1
PF SCALE SCALE,PF,UNIT,ESL,ASP 3.4.5.2
PF ENCODER BOARD ASSY.,ENCODER,PF 3.4.5.3
PF TIMING BELT TIMING BELT,PF 3.4.5.4
PRESSURE ROLLER N/A 3.4.5.5
PRESSURE ROLLER
MOTOR
MOTOR ASSY.,ASF,SUB 3.4.5.6
PRESSURE ROLLER
SENSOR
PHOTO INTERRUPTER 3.4.5.7
ATC MOTOR MOTOR ASSY.,REWIND 3.4.5.8
PE SENSOR
(ROLL PAPER)
PHOTO INTERRUPTER 3.4.5.9
PE SENSOR
(THICK PAPER)
BOARD
ASSY.,DETECTOR,PW;B
3.4.5.10
PAPER THICKNESS
SENSOR
PHOTO INTERRUPTER 3.4.5.11
Cutter Mechanism CUTTER UNIT CUTTER,44,ASSY.,ESL,ASP 3.4.6.1
Fan
BOARD BOX FAN
FAN
ASSY.,ABSORPTION,ASSY.,E
SL,ASP
3.4.7.1
SUCTION FAN DC FAN SET 3.4.7.2
Auto Take-up Reel
TAKE-UP REEL
COVER
COVER,WINDER,DRIVE 3.4.8.1
TAKE-UP REEL
SENSOR
DETECTOR,WINDER 3.4.8.2
TAKE-UP REEL LED INDICATOR,WINDER 3.4.8.3
TAKE-UP REEL
SWITCH
SW,WINDER 3.4.8.4
TAKE-UP REEL PS
BOARD
BOARD ASSY.,POWER
SUPPLY
3.4.8.5
TAKE-UP REEL
MOTOR
MOTOR ASSY.,REWIND 3.4.8.6
TAKE-UP REEL MAIN
BOARD
BOARD ASSY.,MAIN 3.4.8.7
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3 sec.No.)
