Icom ID-51A Advanced Instructions

10
GPS/GPS-A OPERATION
10-14
0.25’ 0.25’
0.25’0.25’
N
Your
position
Your
position
Extended range
(approx. 1 km; 1094 Y)
Limited range
(approx. 500m; 547Y)
Beeps one times Beeps three times
• Alarm area (Group) — Setting plural stations
When all channels or group is selected:
• Alarm area (RX/Memory)— Setting specific stations
When a specified memory is selected:
Point A
Point B
Point C (Beeps three times)
• GPS Alarm beeping screen
GPS memory operation (Continued) ■
D GPS alarm setting
A GPS alarm can sound when a target position comes
into the alarm area.
This function can be set to the caller station, all GPS
Memory channels, a specified Memory group or a
specified Memory channel.
Push [MENU] q
.
Push D-pad( w ) to select the root item (“GPS”), and
then push D-pad(Ent).
D-pad
(�)
(Ent)
Push D-pad( e ) to select “GPS Alarm,” and then
push D-pad(Ent).
Push D-pad( r ) to select “Alarm Select,” and then
push D-pad(Ent).
Push D-pad( t ) to select “Group,” and then push D-
pad(Ent).
Push D-pad( y ) to select “All Memories,” and then
push D-pad(Ent).
• If you wish to set the alarm to a GPS Memory group,
select one between A to Z or “(No Group).”
u Push [MENU] to exit the Menu screen.
• When either one of the stations in a specied group en-
ters its set range, the beep sounds three times.
• When the GPS alarm beeps, “GPS ALARM” pops up on
the screen and then the S icon blinks.
• To cancel the GPS alarm, repeat step t and select
“OFF.”
NOTE: When “Group” is selected in step t, and a
target position enters in the active alarm range spec-
ified in “Alarm area (Group)” of the Menu screen, the
GPS alarm sounds. (p. 16-37)
(MENU > GPS > GPS Set > Alarm Area (Group))
Example: Alarm Area (Group)
Alarm Setting is set to all GPS Memories.
“All Memories”
is displayed.
The pop up is
displayed and
beeps 3 times.
Blinks
