Icom ID-51A Advanced Instructions

18
OPTIONS
18-8
VOX function (Cntinued) ■
D VOX-related settings
The VOX Delay and the VOX time-out timer can be set
in the MENU screen.
• VOX delay
Sets the VOX delay to between 0.5 and 3.0 seconds
(in 0.5 seconds steps). The VOX delay is the amount of
time the transmitter stays ON after you stop speaking.
(Default: 0.5)
(MENU > Function > VOX > VOX Delay)
If “VOX” is intermittent, set the VOX delay long
enough to allow normal pauses in speech, but turn
OFF the VOX after you finish speaking.
• VOX time-out timer
Sets the VOX Time-Out Timer to between 1, 2, 3, 4,
5, 10 and 15 minutes to prevent accidental prolonged
transmission.
To turn OFF the function, select “OFF.” (Default: 3)
(MENU > Function > VOX > VOX Time-out Timer)
The VOX Time-Out Timer must be set shorter than
the transceiver Time-Out Timer, otherwise this timer
will not be activated.
■ SJ-1 s i l i c o n e j a c k e t
The SJ-1 s i l i c o n e j a c k e t can be used when the BP-
271 b at t e r y p a c k is attached to the transceiver.
When the BP-272 b at t e r y p a c k or BP-273 b at t e r y
c a s e is attached, the jacket cannot be used.
Before attaching or removing the jacket, be sure to
disconnect the antenna from the transceiver.
To attach:
Place the antenna connector and [DIAL] of the q
transceiver into the holes on the top of the jacket, as
shown to the right.
Pull the jacket around the sides and bottom of the w
transceiver.
 •Whenthebeltclipisattached,pushitoutfromthehole
on back of the jacket.
To remove:
Remove the jacket from bottom of the transceiver. q
 •Ifabeltclipisattached,pullthejacketaroundthebottom
of the clip.
Pull the antenna connector and [DIAL] from the jack- w
et, and remove it from the transceiver.
