15
REPEATER AND DUPLEX OPERATIONS
15-4
■ Duplex operation
The Duplex operation shifts the transmit frequency
up or down from the receive frequency by an offset
amount.
D Setting the frequency offset
Push [V/MHz] q to select the VFO mode.
Push [MENU] w .
Push D-pad( e ) to select the root item (“DUP/
TONE...”), and then push D-pad(Ent).
Push D-pad( r ) to select the “Offset Freq,” and then
push D-pad(Ent).
Rotate [DIAL] to set the frequency offset to be- t
tween 0.000.00 and 59.99500 MHz, and then push
D-pad(Ent). (Setting example: 1.000.00 MHz)
• The selected tuning step in the VFO mode is used when
setting the frequency offset.
• Pushing [V/MHz]
toggles the tuning digit, as shown
below.
* The frequency changes according to the preset tuning
steps. (p. 5-6)
Push [MENU] y to exit the [MENU] screen.
To reset to the default value.
Push [QUICK] in step t as described above, then
push D-pad(Ent) to reset to the default value.
NOTE:
• The frequency offset cannot be changed in the DR
mode.
• The Auto repeater function uses the preset fre-
quency offset. Depending on the frequency offset
value, the off band indication, “OFF,” appears on
the display when [PTT] is pushed. (p. 15-5)
The current frequency
offset
Rotate [DIAL], then
push D-pad(Ent).
Push [QUICK]
Push D-pad(Ent)
[DIAL]
The current frequency
offset
To Next Page
