3
PANEL DESCRIPTION
3-5
q BATTERY ICON
Shows the capacity of the attached battery pack ➥
in four levels. (p. 4-2)
•“ ” (battery icon) appears when the battery
pack is attached.
•“ ” appears when the battery pack must be
charged.
“ ➥
” appears when the optional battery case is
attached. (p. 4-4)
w VOX ICON (p. 18-6)
Appears when the optional headset is connected
with the OPC-2006LS p l u g a d a p t e r c a b l e , and the
VOX function is ON.
e OPERATING MODE ICONS (p. 5-7)
Shows the selected operating mode.
•DV,AM,FMandFM-Nareselectable.
•“DV-G”or“DV-A”appearswhenGPSorGPS-Atransmis-
sion is selected in the DV mode. (p. 10-16)
r EMR/BK/Packet Loss/Auto Reply ICON
“EMR”appearswhentheEnhancedMonitorRe- ➥
quest(EMR)modeisselected.(p.9-8)
“BK”appearswhentheBreak-in(BK)modeisse- ➥
lected.(p.9-7)
“L” appears when Packet Loss has occurred. ➥
(p.9-14)
“ ➥ ” appears when the Automatic Reply function
isselected.(p.9-11)
t DUPLEX ICON (p. 15-5)
“DUP+”appearswhenplusduplexisselected,and
“DUP–”appearswhenminusduplexisselected.
y BC RADIO ICON (p. 6-2)
AppearswhentheBCradioisON.
u GPS ICON
AppearswhileGPSfunctionisinuse.(p.10-2) ➥
StaysONwhentheGPSreceiverisactivatedand
valid position data is received.
Blinks when invalid position data is being re-
ceived.
•GPSiconscanbeturnedOFFintheMenuscreen.
(p. 16-33)
“ ➥ S”blinksinsteadoftheGPSicon,whenthe
GPSalarmbeeps.(p.10-14)
i RECORD ICON (p. 11-2)
Appears while recording.
•“ ” appears while the transceiver is recording.
•“
” appears while the recording is paused.
o microSD ICON (Section 2)
“ ➥ ” appears when a microSD card is inserted.
“ ➥ ”and“ ” alternately blinks while accessing the
microSD card.
!0AUTO POWER OFF ICON (p. 16-83)
AppearswhentheAutopowerOFFfunctionisON.
■ Function display
Single band display
BC Radio setting pop-up
window (Tuning mode)
Dual band display
q
w r y u io !0 !2
!3
!5
!6
!7
!8
!9
@0
!1
te
@1
@2
@3
!4
