3-80 Operating the monitor screen
3Explanation of operation methods
7) Press the function key corresponding to "CLOSE", and return to the monitor menu screen.
(5) Variable monitor
It is the function to display or change the details of the variable currently used by the program.
1) Press the [5] key in the monitor menu screen, and display the variable monitor screen.
2) Specify the target program of the monitor with the slot number.
Press the function key corresponding to "SLOT", and input the slot number.
Set up "1", if the multitasking function is not being used.
3) Display the slot number and the program name after "slot:".
Press the function key corresponding to the "NAME", and input the variable name to monitor.
<MONITOR>　　 　
1.INPUT 2.OUTPUT
3.INPUT REG. 4.OUTPUT REG.
5.VARIABLE 6.ERROR LOG
CLOSE
　 123
<FILE/EDIT> 1/20 Rem 136320
1 08-04-24 17:20:32 22490
2 08-04-24 14:56:08 694
A1 08-04-24 13:05:54 2208
B1 08-04-24 13:05:54 1851
COPY
123
POSI.
EDIT
NEW
⇒
Finish the monitor
If the [MONITOR] key is pressed, the monitor will be finished always and it will return to the original screen.
<MONITOR>　　 　
1.INPUT
2.OUTPUT
3.INPUT REG. 4.OUTPUT REG.
5.VARIABLE 6.ERROR LOG
CLOSE
　 123
<VARIABLE>
SLOT : 1 TEST
=
=
=
CLOSE
123
VALUE
SLOT
NAME
<VARIABLE>
SLOT ( 1_ )
CLOSE
123
<VARIABLE>
SLOT : 1 TEST
=
=
=
CLOSE
123
VALUE
SLOT
NAME
<VARIABLE>
SLOT : 1 5
=
=
=
CLOSE
123
VALUE
SLOT
NAME
<VARIABLE>
NAME ( M1_ )
CLOSE
123
To Next Page
