3-72 Operation of operating screen
3Explanation of operation methods
4) Press the function key corresponding to "CLOSE", and return to the operation menu screen.
3.13.3 Operating the OPERATION screen
Turning on and off the servo power, selecting the program, starting of automatic operation, etc can be done.
Refer to Page 53, "3.8.3 Starting automatic operation".
<RUN>　　 　
1.CHECK 2.TEST RUN
3.OPERATION
CLOSE
　 123
<TEST RUN>
1 Mov P1
PROG.NAME: 1 STEP: 1
MODE: CONT.
CLOSE
123
⇒
CSTOP
If execution of the program is stopped, it will become the continuation mode of operation.
If the [STOP] key is pressed in the cycle mode of operation and execution of the program is stopped, it
changes to the continuation mode of operation. If it continues execution of the program by the cycle mode of
operation, please press the [F4] key again after pushing the [START] button. (It also becomes the cycle
mode of operation to push the [END] button of the controller)
To Next Page
