5Functions set with parameters
About the output signal reset pattern 5-487
5.14 About the output signal reset pattern
The factory default setting sets all general-purpose output signals to OFF (0) at power up. The status of gen-
eral-purpose output signals after power up can be changed by changing the following parameter. Note that
this parameter also affects the general-purpose output signal reset operation (called by dedicated I/O sig-
nals) and the reset pattern after executing the Clr instruction.
Parameter name Value (Values are all set to 0 at the factory default setting.)
Remote I/O
ORST0 Signal number
0----------7 8---------15 16--------23 24--------31
00000000, 00000000, 00000000, 00000000
ORST32 32--------40 41--------49 50-------57 58-------66 (Same as above)
00000000, 00000000, 00000000, 00000000
ORST64 00000000, 00000000, 00000000, 00000000
ORST96 00000000, 00000000, 00000000, 00000000
ORST128 00000000, 00000000, 00000000, 00000000
ORST160 00000000, 00000000, 00000000, 00000000
ORST192 00000000, 00000000, 00000000, 00000000
ORST224 00000000, 00000000, 00000000, 00000000
PROFIBUS option
ORST2000 00000000, 00000000, 00000000, 00000000
ORST2032 00000000, 00000000, 00000000, 00000000
ORST2064 00000000, 00000000, 00000000, 00000000
ORST2096 00000000, 00000000, 00000000, 00000000
ORST2128 00000000, 00000000, 00000000, 00000000
ORST2160 00000000, 00000000, 00000000, 00000000
ORST2192 00000000, 00000000, 00000000, 00000000
ORST2224 00000000, 00000000, 00000000, 00000000
ORST2256 00000000, 00000000, 00000000, 00000000
ORST2288 00000000, 00000000, 00000000, 00000000
: :
: :
: :
ORST5008 00000000, 00000000, 00000000, 00000000
ORST5040 00000000, 00000000, 00000000, 00000000
CC-Link option
ORST6000 00000000, 00000000, 00000000, 00000000
ORST6032 00000000, 00000000, 00000000, 00000000
ORST6064 00000000, 00000000, 00000000, 00000000
ORST6096 00000000, 00000000, 00000000, 00000000
ORST6128 00000000, 00000000, 00000000, 00000000
ORST6160 00000000, 00000000, 00000000, 00000000
ORST6192 00000000, 00000000, 00000000, 00000000
ORST6224 00000000, 00000000, 00000000, 00000000
ORST6256 00000000, 00000000, 00000000, 00000000
ORST6288 00000000, 00000000, 00000000, 00000000
: :
: :
: :
ORST7984 00000000, 00000000, 00000000, 00000000
ORST8016 00000000, 00000000, 00000000, 00000000
