7Appendix
Spline interpolation Appendix-651
(12) Copying the spline file
In RT ToolBox2 Ver. 3.20W or later, spline files can be copied on the project tree.
By selecting the spline file to be copied on the project tree, and then dragging and dropping it to [Spline]/
[Online]/[Offline] in the copy destination project tree, a dialog box appears to confirm the selection.
Fig.7-68:Copying the spline file
By clicking the [Yes] button, the specified spline file is copied.
By clicking the [No] button, copying is canceled.
If a spline file with spline No. that already exists in the copy destination is copied, an overwrite confirmation
dialog box appears.
Fig.7-69:Overwrite confirmation dialog box
(13) Spline file manager
A Spline file manager screen has been added for RT ToolBox2 Ver. 3.40S or later.
Select [Online] → [Spline] for projects for which spline file management is to be performed, and right-click.
Click [Spline file manager] in the context menu that appears to display the Spline file manager screen.
(Menu [File] → [Spline file manager])
Fig.7-70:Spline file manager screen
To Next Page
