6-548 Sequencer input/output unit direct control
5Functions set with parameters
(5) Description of the Robot Status Variable
Explains the outline of the Robot Status Variable to Table 5-46. Refer to each description page of Page 311,
"4.14.2 Explanation of Each Robot Status Variable" for details.
Table 5-46:Related Robot Status Variable
Variable
name
Details
Reference
page
M_XDev Reads the sequencer input signal (X) per bit.
ex.) 1 M1%=M_XDev (1) ' The value of the sequencer input signal 1 (1 or 0) is sub-
stituted to M2.
Page 377
M_XDevB Reads the sequencer input signal (X) per byte.
ex.) 1 M2%=M_XDevB(&H10) ' The value of 8-bit width from 10 (hexadecimal number)
of sequencer input signals is substituted to M2.
Page 377
M_XDevW Reads the sequencer input signal (X) per word.
ex.) 1 M4%=M_XDevW(&H20) ' The value of 16-bit width from 20 (hexadecimal number)
of sequencer input signals is substituted to M4.
Page 377
M_XDevD Reads the sequencer input signal (X) per double word.
ex.) 1 M5&=M_XDevD(&H100) ' The value of 32-bit width from 100 (hexadecimal num-
ber) of sequencer input signals is substituted to M5.
Page 377
M_YDev Reads/Writes the sequencer output signal (Y) per bit.
ex.) 1 M_YDev(2)=1 Dly 0.5 'Turns on the sequencer output signal 2 for the 0.5 sec-
onds (pulse output).
Page 379
M_YDevB Reads/Writes the sequencer output signal (Y) per byte.
ex.) 1 M_YDevB(&H10)=&HFF 'Turns on the 8-bit width from 10 (hexadecimal number)
of sequencer output signals.
Page 379
M_YDevW Reads/Writes the sequencer output signal (Y) per word.
ex.) 1 M_YDevW(&H20)=&HFFFF ' Turns on the 16-bit width from 20 (hexadecimal number)
of sequencer output signals.
Page 379
M_YDevD Reads/Writes the sequencer output signal (Y) per double word.
ex.) 1 M_YDevD(&H100)=P1.X * 1000 ' Outputs the multiplication result value of X coordinate
value of the position variable P1 by 1000 to 32-bit width
from 100 (hexadecimal number) of sequencer output
signals.
Page 379
