9
UTILITY OPERATION
9.2 C Controller Setting Utility
9.2.10 Operating Communication diagnostics screen
9 - 53
9
UTILITY OPERATION
10
FUNCTIONS AND
PROGRAMMING
11
OVERVIEW OF
MULTIPLE CPU
SYSTEM
12
MULTIPLE CPU
SYSTEM
CONFIGURATION
13
MULTIPLE CPU
SYSTEM
CONCEPT
14
COMMUNICATIONS
BETWEEN CPU
MODULES
15
PARAMETERS
ADDED FOR
MULTIPLE CPU
16
PRECAUTIONS FOR
USE OF AnS SERIES
MODULE
* 1 Refer to the following for details of the error code.
Section 18.4.1
Table9.29 Explanation of Communication diagnostics screen
Item Description
Reference
section
Communication
diagnostics
Target CPU
Select the CPU to be diagnosed.
(Initial value: "No. 1", Setting range: "No. 1" to "No. 4")
Repeat count
Specify the number of times communication diagnostics will be
performed.
(Initial value: 5, Setting range: 1 to 32767)
button
Executes communication diagnostics. During diagnostics, this button
switches to .
button
Stops communication diagnostics. During diagnostics stop, this button
switches to .
Execution count
Displays the number of times communication diagnostics have been
performed.
Result
"Normal" appears when the communication diagnostics result is normal.
"Error" appears when the result is abnormal.
"It is diagnosing" appears during execution of communication diagnostics.
Mean time to
communicate
Displays the mean time taken for communication.
Error code
*1
Displays the error code of the communication diagnostics result.
System setting I/O assignment setting Multiple CPU setting
Communication diagnostics
Start
Stop
Stop
Start
