Mitsubishi MELSEC Q Series User Manual

2 - 4
2.1 System Configuration
2.1.2 Connection with development environment
2
SYSTEM CONFIGURATION
2.1.2 Connection with development environment
* 1 To write a user file to the CompactFlash card requires a personal computer(e.g. a notebook
computer) that has a PCMCIA interface, or a computer with a CompactFlash card reader/writer
connected.
* 2 For the specifications and inquiries of Tornado, visit the Wind River Systems, Inc. website:
http://www.windriver.com/
Figure 2.3 Connection with environment development
Development environment*
1
(personal computer)
C Controller module
Commercially available
CompactFlash card
(to be purchased separately)
Commercially available
CompactFlash card
(to be purchased separately)
Twisted pair cable
(Crossing cable)
(to be purchased separately)
Adaptor*
1
(to be purchased
separately)
Tornado*
2
(to be
purchased separately)
SW PVC-CCPU
