9
UTILITY OPERATION
9.3 CC-Link utility
9.3.7 Operating Test screen
9 - 83
9
UTILITY OPERATION
10
FUNCTIONS AND PROGRAMMING
11
OVERVIEW OF MULTIPLE CPU SYSTEM
12
MULTIPLE CPU SYSTEM CONFIGURATION
13
MULTIPLE CPU SYSTEM CONCEPT
14
COMMUNICATIONS BETWEEN CPU MODULES
15
PARAMETERS ADDED FOR MULTIPLE CPU
16
PRECAUTIONS FOR USE OF AnS SERIES MODULE
Table9.53 Explanation of Test screen
Item Description
Target module
Select the module to be tested.
(Initial value: "1 Slot", Setting range: "1 Slot" to "8 Slot")
Start I/O No. Displays the start I/O No. of the CC-Link module.
Self station information
Displays the station No., station type ("Master station" or "Local station") and operating
mode of the CC-Link module selected in "Target module".( Section 9.3.2 (1)(a))
Test it em
Select the test to be executed.
Display Description
Line test
Tests whether the connected station is in a data link
enabled status or not. (Can be selected only for the master
station)
Network test Tests a data link start and stop.
button
Performs the test selected in the above "Test item".
Line test ...........
This section (2)(a)
Network test ..... This section (2)(b)
Module information Other station monitor Online operation Parameter setting Target setting
Test
Start
