10
FUNCTIONS AND PROGRAMMING
10.3 Programming Using MELSEC Data Link Functions
10.3.12 Accessible ranges and devices of MELSEC data link functions
10 - 56
9
UTILITY OPERATION
10
FUNCTIONS AND
PROGRAMMING
11
OVERVIEW OF
MULTIPLE CPU
SYSTEM
12
MULTIPLE CPU
SYSTEM
CONFIGURATION
13
MULTIPLE CPU
SYSTEM
CONCEPT
14
COMMUNICATIONS
BETWEEN CPU
MODULES
15
PARAMETERS
ADDED FOR
MULTIPLE CPU
16
PRECAUTIONS FOR
USE OF AnS SERIES
MODULE
(3) Access via MELSECNET/H module
The following explains the accessible range and devices when access is made via a
MELSECNET/H module.
(a) Accessible range
This section provides a system configuration for access via a MELSECNET/H
module and a table showing accessibility of each target CPU.
1) System configuration
2) Accessibility table
The following table indicates whether access can be made or not for each
case.
The self station and connected station CPUs are all accessible.
: Accessible, : Inaccessible
* 1 Access is allowed when the MELSECNET/H module of the connected station is in the
MELSECNET/H mode.
* 2 Access is allowed when the MELSECNET/10(H) module of the connected station is in the
MELSECNET/10 mode.
Figure 10.24 Accessible range for access via MELSECNET/H module
Table10.25 Accessibility table
1.Connected
network
2.Connected
station CPU
3.Relayed network
4.Target CPU
QCPU
QnACPU ACPU
C Controller
module, PC
CPU module
MELSECNET/
H board (PC)
Q mode A mode
MELSECNET/H
QCPU
(Q mode)
MELSECNET/H
*1
MELSECNET/10
*2
MELSECNET(II)
Ethernet
Computer link
CC-Link
MELSECNET/10
QCPU
(Q mode)
MELSECNET/H
MELSECNET/10
MELSECNET(II)
Ethernet
Computer link
CC-Link
QnACPU
MELSECNET/H
MELSECNET/10
MELSECNET(II)
Ethernet
Computer link
CC-Link
QCPU
(A mode), ACPU
MELSECNET/H
MELSECNET/10
MELSECNET(II)
Ethernet
Computer link
CC-Link
1
2
3
4
C Controller module
Connected network
Connected
station CPU
Connected
module
Relayed
module
Target
CPU
Destination
module
Relayed network
To Next Page
