Ricoh Aficio MP 8001 Service Manual

Copy Tray (B756)
SM 2-87 D062/D063/D065/D066
Installation
2.15 COPY TRAY (B756)
2.15.1 ACCESSORIES
Check the accessories and their quantities against the following list.
Description Q’ty
1. Copy Tray 1
2. Actuator Arm and Bracket (not used) 1
3. Tapping Screw (not used) 2
4. Large Cap 1
5. Small Cap 4
6. Tapping Screw (M4 x 8) 1
7. Harness Clamp 1
8. Paper Height Sensor 1
9. Actuator Arm Bracket 1
10. Sensor Bracket 1
11. Actuator Arm 1
