Copy Image Adjustments: Printing/Scanning
D062/D063/D065/D066 4-138 SM
4.14.3 ADF SCANNING ADJUSTMENTS
Vertical Black Lines
Vertical black lines in scanned images may be caused by dust or scratches on the ADF
exposure glass. If the problem cannot be solved by cleaning the ADF exposure glass,
execute SP4018 (Scanner Optical Axis Adjustment).
1. Adjust the scanner stopping position with SP4018-003 (just input a new value).
2. Store this value in the machine with SP4018-004.
3. Adjust the ADF registration for the front side scan with SP6006-003.
4. Make a test copy to check that the problem has been solved.
DIP Switch Settings (ADF Main Board)
SW 101 Operation Mode
1 2 3 4
OFF OFF OFF OFF I/F Operation
ON OFF OFF OFF Free run (Simplex: each sheet stopped for registration)
OFF ON OFF OFF Free run (Simplex: continuous scanning)
ON ON OFF OFF Free run (Duplex: no registration) SP6009 (ADF Free Run)
ON OFF ON OFF Not used.
OFF ON ON OFF
ON ON ON OFF
OFF OFF OFF ON
ON OFF OFF ON Free run (Entrance mode *1, simplex, no registration)
OFF ON OFF ON Free run (Entrance mode, simplex, continuous scanning)
OFF ON ON ON Motor test (feed, transport, exit motors)
*1: The entrance mode disregards paper size. Skew correction is performed at the
scanning roller.
