Punch Unit (B531)
D062/D063/D065/D066 2-48 SM
2.8 PUNCH UNIT (B531)
The Punch Unit B531/B812 can be installed only in the 3000-Sheet Finisher D460.
2.8.1 ACCESSORY CHECK
Check the accessories and their quantities against this list:
Description Q"ty
1. Punch unit 1
2. Harness Connector Cable - PCB 1
3. Harness Connector Cable - HP Sensor 2 1
4. Harness Connector Cable - HP Sensor 1, Hopper Full 1
5. Sensor Arm and Sensor 1
6. Spacer (2 mm) 1
7. Spacer (1 mm) 2
8. Spring 1
9. Step Screw (large) (M4 x 11) 1
10. Tapping Screw (M4 x 10) 2
11. Step Screw (small) (M3 x 4) 1
12. Machine Screw, Washer (M4 x 6) 1
13. Knob 1
14. Punch Waste Hopper 1
To Next Page
