MFP Options
SM 2-109 D062/D063/D065/D066
Installation
17. Reattach the SD card slot cover.
18. Return copied SD cards to the customer for safekeeping, or tape the copied SD cards
to the inside of the front door.
Do not remove copied SD cards from the machine site.
After an SD card has been copied, it can no longer be used. However, it must be
stored in the machine to serve as proof of purchase by the customer.
The original card can also be used to perform an undo procedure (SP 5873 002).
Before you store an SD card, label it carefully so it can be identified easily if you
need to do the undo procedure (see below).
Undo Exec
Do this procedure if you moved an option from the original SD card to another card by
mistake and you need to restore the original SD card.
1. Turn the main switch OFF.
2. Put the SD card holding the merged applications in SD Card Slot 1.
3. Put the original destination SD card (the one removed from storage) into Slot 2
The SD card in Slot 2 must be the original SD card of the application you want
to move from Slot 1 to Slot 2. You cannot use a blank SD card in Slot 1.
4. Turn the main switch ON.
5. Do SP5873-002 (Undo Exec).
6. Follow the instructions of the operation panel messages.
7. Turn the main switch OFF.
8. Remove the SD cards from the slots.
9. Turn the main switch ON.
2.20.2 COMMON PROCEDURES
Inserting SD Cards
Insert SD cards with the notched corner down.
The insertion point for the SD cards are offset slightly to the left. Make sure the SD card is
inserted correctly before you push it into the slot.
Pushing in the SD Card also releases it for removal. Make sure the SD Card is inserted and
locked in place. If it is partially out of the slot, push it in gently until it locks in place.
Rev. 08/03/2009
