MFP Options
D062/D063/D065/D066 2-122 SM
install the components in the box. Contact your sales division.
2. If the surfaces of the tapes do not show "VOID", remove them from the corners of the
box.
3. After you remove each seal, the "VOID" marks [B] become visible. This prevents them
from being reattached to the box.
Installation
The DOS SD card must be inserted in SD card Slot 1.
If the PostScript3 option is also installed, you must move the DOS application to
the PostScript3 SD card with SP5873 -1.
1. If the machine is on, turn off the main power switch.
2. Disconnect the network cable.
3. Turn the main power switch on.
4. Turn the operation switch and main power switch off.
5. Remove the SD card slot cover (
x1).
6. Insert the SD card into SD card Slot 1.
7. Reconnect the network cable.
8. Turn the main power switch on.
9. Do SP5878-001 and push [EXECUTE].
10. Go out of the SP mode.
11. Turn the operation switch off, then turn the main power switch off.
12. Do SP5990-5 to print an SMC report.
13. Make sure the ROM number and firmware version in area [a] of the diagnostic report
are the same as those in area [b].
Area [a]: "ROM Number/Firmware Version" – "HDD Format Option"
Area [b]: "Loading Program" - "GW4a_zoffyx"
Diagnostic Report:
"ROM No. / Firmware
Version" [a]
"Loading Program" [b]
DataOverwriteSecurity Unit
HDD Format Option:
D3775902A / 1.01x
GW4a_zoffyx:
D3775902A / 1.01x
The same two numbers must be listed in both sections of the SMC report
If the numbers are not identical, this means the option was not installed correctly.
Rev. 08/03/2009
