Key Card Bracket (B498), Key Counter Bracket (B452)
SM 2-91 D062/D063/D065/D066
Installation
2.16.2 KEY COUNTER BRACKET B452 ACCESSORIES
Check the accessories and their quantities against this list.
Description Qty
1. Plate nuts 2
2. Rear Bracket 1
3. Front Bracket 1
4. Tapping Screws (M3 x 6) 2
5. Tapping Screws (M4 x 8) 3
6. Tapping Screws (M4 x 16) 2
7. Harness 1
8. Shoulder Screw 1
9. Key Counter Bracket Cover 1
10. Key Counter Bracket 1
