Document Feed Components
D366 2 SM
1.2 DOCUMENT FEED COMPONENTS
1.2.1 ORIGINAL FEED UNIT
1. Open the left cover.
2. Original feed unit [A].
1.2.2 PICK-UP ROLLER
1. Open the left cover.
2. Original feed unit (
"Original Feed Unit")
3. Pick-up roller [A] (
x 1)
