SPECIFICATIONS
SM 1 D385
Internal Shift
Tray SH3010
D385
1 OVERALL MACHINE INFORMATION
1.1 SPECIFICATIONS
Paper Size: Standard Size:
A5 lengthwise to A3
HLT lengthwise to DLT
Non-standard Size:
Paper Width: 90 ~ 297 mm
Paper Length: 148 ~ 432 mm
Paper Weight: 60 ~ 105 g/m², 16 ~ 28 lbs.
Tray Capacity: 125 sheets (80 g/m², 20 lbs.): B4 or larger
250 sheets (80 g/m², 20 lbs.): A4 or smaller
Power Source: 5 VDC, 24 VDC (from the copier)
Power Consumption: 17 W
Weight: 1.1 kg
Size (W x D x H):
530 mm x 410 mm x 120 mm
