By-pass Unit

SM 9 D369

Duplex Unit

AD3000

D369

1.3 BY-PASS UNIT

1.3.1 PAPER END SENSOR (BYPASS)

1. Duplex unit ( Duplex Unit)

2. By-pass Tray ( By-pass Tray)

3. Right door cover ( Right Door Cover)

4. Release the hook [A].

5. Sensor base [B] ( x 1)

6. Paper end sensor (bypass) [C] (hooks)

1.3.2 BY-PASS FEED ROLLER

1. Duplex unit ( Duplex Unit)

2. By-pass Tray ( By-pass Tray)

3. Right door cover ( Right Door Cover)

4. Sensor base (Paper End Sensor (Bypass))
