DRIVE LAYOUT
SM 5 D368
Bridge Unit
BU3020
D368
1.5 DRIVE LAYOUT
1. Left Exit Roller
2. 2nd Transport Roller
3. 1st Transport Roller
4. Upper Exit Roller
5. 3rd Transport Roller
6. Bridge Unit Drive Motor
B417V502.WMF
4
5
6
1
3
2
