System SP Tables-2
D017/D018/D019/D020/D084/D085 4-10 SM Appendix
4.2 SYSTEM SP TABLES-2
4.2.1 SP2XXX: DRUM
2001* Charge Bias
1*
Setting (Copying)
Adjusts the voltage applied to the charge roller during printing.
This value will be changed automatically when the charge roller bias
correction is performed.
Note that if this value is changed, the charge roller voltage will be corrected
based on the new voltage.
[2100 to 1500 / –1700 / 1 V/step]
2*
ID Sensor Pattern
Adjusts the voltage applied to the charge roller when making the Vsdp ID
sensor pattern (for charge roller bias correction).
The actual charge roller voltage is this value plus the value of SP2001 1.
[0 to 400 / 200 / 1 V/step]
3
Temporary Input
Inputs the charge roller voltage temporarily for test purposes.
Do not change the value.
[0 to –2500 / 0 / 1 V/step]
