Transfer Unit
SM 4-36 D017/D018/D019/D020/D084/D085
4.6.2 IMAGE DENSITY SENSOR
1. Open the right cover.
2. Remove:
[A] Transfer roller
[B] Roller guide (
x1, x1)
3. Remove:
[A] Image density sensor (
x1).
4. Initialize the new sensor with SP2935.
