Rockwell Automation Publication 2198-UM001M-EN-P - November 2022 145
Chapter 7 Troubleshoot the Kinetix 5500 Drive System
Fault Codes
NODE ALARM xx
Exceptions that can prevent normal operation of the drive module, but do not result in
any action other than reporting the alarm to the controller.
INHIBIT Sxx
Conditions that prevent normal operation and indicate that the drive module is
prevented from being enabled.
INHIBIT Mxx
ALARM Sxx
An underlying exception condition that does not result in any action other than reporting
the alarm to the controller.
ALARM Mxx
SAFE FLTxx Exception that is generated by a fault condition that is detected in the safety function.
(1) Sxx refers to Standard exceptions.
(2) Mxx refers to Manufacturer-specific exceptions.
Fault codes that are triggered by conditions that fall outside factory-set
limits are identified by FL at the end of the display message. For
example, FLT S07 – MTR OVERLOAD FL.
Fault codes that are triggered by conditions that fall outside user-set
limits are identified by UL at the end of the display message. For
example,
FLT S08 – MTR OVERLOAD UL.
This manual links to Kinetix 5500 Servo Drive Fault Codes Reference
Data, publication 2198-RD005
, for fault codes. Download the
spreadsheet now for offline access.
Table 60 - Fault Code Summary (Continued)
Fault Code Type
(1)
(2)
Description
