Rockwell Automation Publication 2198-UM001M-EN-P - November 2022 87
Chapter 5 Connect the Kinetix 5500 Drive System
Motor Power and Brake Connections
The motors and actuators in Table 47 have separate power/brake and feedback
cables. The motor power/brake cable attaches to the cable clamp on the drive
and the power/brake conductors attach to the MP and BC connectors,
respectively.
See Motor Power Connections
on page 81 and Motor Brake Connections on
page 82 for the MP and BC connector specifications.
Table 47 - Current Motor Power Cable Compatibility
Motor/Actuator Cat. No.
(1)
(1) The 2198-H2DCK (series B or later) feedback converter kit is required.
Motor Power Cat. No.
(2)
(with brake wires)
(2) See the Kinetix Rotary and Linear Motion Cable Specifications Technical Data, publication KNX-TD004, for cable
specifications.
Motor Power Cat. No.
(2)
(without brake wires)
MPL-A/B15xxx-xx7xAA, MPL-A/B2xxx-xx7xAA,
MPL-A/B3xxx-xx7xAA, MPL-A/B4xxx-xx7xAA,
MPL-A/B45xxx-xx7xAA, MPL-A/B5xxx-xx7xAA,
MPL-B6xxx-xx7xAA
2090-CPBM7DF-xxAAxx
(standard) or
2090-CPBM7DF-xxAFxx
(continuous-flex)
2090-CPWM7DF-xxAAxx
(standard) or
2090-CPWM7DF-xxAFxx
(continuous-flex)
MPM-A/Bxxxx, MPF-A/Bxxxx, MPS-A/Bxxxx
MPAS-A/Bxxxx1-V05SxA, MPAS-A/Bxxxx2-V20SxA,
MPAI-A/Bxxxx, MPAR-A/B3xxx, MPAR-A/B1xxx, and
MPAR-A/B2xxx (series B)
LDAT-Sxxxxxx-xDx —
Table 48 - Legacy Motor Power Cables
Motor Cable Description Motor Power Cat. No.
Standard
Power/brake, threaded 2090-XXNPMF-xxSxx
Power-only, bayonet 2090-XXNPMP-xxSxx
Continuous-flex
Power/brake, threaded 2090-CPBM4DF-xxAFxx
Power-only, threaded 2090-CPWM4DF-xxAFxx
Power-only, bayonet 2090-XXTPMP-xxSxx
Table 49 - Induction Motor Power Cable Specifications
Cable Manufacturer Cable Series Voltage Rating Temperature Rating
Belden 29500…29507
600V 90 °C (194 °F)Lapp Group ÖLFEX VFD XL
SAB VFD XLPE TR
