Rockwell Automation Publication 2198-UM001M-EN-P - November 2022 67
Chapter 5
Connect the Kinetix 5500 Drive System
This chapter provides procedures for wiring your Kinetix® 5500 system
components and making cable connections.
Topic Page
Basic Wiring Requirements 68
Determine the Input Power Configuration 69
Ground Screw Settings 72
Remove the Ground Screws in Select Power Configurations 73
Ground the Drive System 74
Wiring Requirements 76
Wiring Guidelines 77
Wire the Power Connectors 78
Wire the Digital Input Connectors 80
Wire Kinetix VP Motors and Actuators 80
Wire Other Motors and Actuators 86
Capacitor Module Connections 96
External Passive-shunt Resistor Connections 97
Ethernet Cable Connections 98
