Chapter 3 Mount the Kinetix 5500 Drive System
Drill-hole Patterns Hole patterns for drives that are mounted in zero-stack or shared-bus
configuration are provided for mounting your drives to the panel. Drives with
the highest power rating are always mounted to the left of any drive with a
lower power rating in shared-bus configurations:
• Frame 1 drives can be followed by only another frame 1 drive.
• Frame 2 drives can be followed by frame 1 drives or another frame 2
drive.
• Frame 3 drives can be followed by frame 1, frame 2, or another frame 3
drive.
• Mount Bulletin 2198 capacitor modules in the rightmost position.
- Capacitor modules have the same hole pattern as frame 2 drives.
- Only Shared DC, Shared AC/DC, and Shared AC/DC, hybrid
configurations are compatible with Bulletin 2198 capacitor modules.
Table 20 - Hole Pattern Overview
Drive Cat. No. Frame Size Frame Size Patterns Page
2198-H003-ERSx
2198-H008-ERSx
Frame 1 As many as eight frame 1 drives
51
2198-H015-ERSx
2198-H025-ERSx
2198-H040-ERSx
Frame 2
As many as eight frame 2 drives
One frame 2 drive followed by as many as seven frame 1 drives 52
2198-H070-ERSx Frame 3
As many as eight frame 3 drives 53
One frame 3 drive followed by as many as seven frame 1 drives 54
One frame 3 drive followed by as many as seven frame 2 drives 55
Table 21 - Capacitor Module Support
Drive Cat. No.
Frame Size
Standalone
Single-phase
Operation
Three-phase Operation
Standalone Shared DC Shared AC/DC
Shared AC/DC
Hybrid
Number of Capacitor Modules Connected, Max
2198-H003-ERSx
(1)
(1) Catalog number 2198-H003-ERS and any drive in standalone single-phase operation is not compatible with the Kinetix 5500
capacitor module.
1
0
0
2198-H008-ERSx
(1)
1
2
2198-H015-ERSx
(1)
24
2198-H025-ERSx
—
3
2198-H040-ERSx
2198-H070-ERSx 34
