Request ID, control → converter
AK Description Response ID
positive nega‐
tive
0 No request 0 7 / 8
1 Request parameter value 1 / 2 7 / 8
2 Change parameter value (word) 1 7 / 8
3 Change parameter value (double word) 2 7 / 8
4 Request descriptive element
1)
3 7 / 8
6
2)
Request parameter value (󹪝eld)
1)
4 / 5 7 / 8
7
2)
Change parameter value (󹪝eld, word)
1)
4 7 / 8
8
2)
Change parameter value (󹪝eld, double word)
1)
5 7 / 8
9 Request number of 󹪝eld elements 6 7 / 8
1)
The required element of the parameter is speci󹪝ed in IND (2nd word).
2)
The following request IDs are identical: 1≡6, 2≡7 3≡8.
We recommend that you use identi󹪝ers 6, 7, and 8.
Response ID, converter → control
AK Description
0 No response
1 Transfer parameter value (word)
2 Transfer parameter value (double word)
3 Transfer descriptive element
1)
4 Transfer parameter value (󹪝eld, word)
2)
5 Transfer parameter value (󹪝eld, double word)
2)
6 Transfer number of 󹪝eld elements
7 Converter cannot process the request.
In the most signi󹪝cant word of the parameter channel, the converter sends an error number to
the control, refer to the following table.
8 No master controller status / no authorization to change parameters of the parameter channel
interface
1)
The required element of the parameter is speci󹪝ed in IND (2nd word).
2)
The required element of the indexed parameter is speci󹪝ed in IND (2nd word).
Error numbers for response ID 7
No. Description
00 hex Illegal parameter number (access to a parameter that does not exist)
01 hex Parameter value cannot be changed (change request for a parameter value that cannot be
changed)
02 hex Lower or upper value limit exceeded (change request with a value outside the value limits)
03 hex Incorrect subindex (access to a subindex that does not exist)
04 hex No array (access with a subindex to non-indexed parameters)
05 hex Incorrect data type (change request with a value that does not match the data type of the
parameter)
Advanced commissioning
7.5Drive control via PROFINET
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 151
