1130 Bearing 1304 Parallel key
1131 Shim 1305 Helical gear
1133 NILOS ring 1306 Parallel key
1135 Locking ring 1308 Locking ring
1136 Locking ring 1309 Seal
1140 Bearing 1401 Screw plug
1144 Supporting disk/shim 1420 Vent 󹪝lter
1145 Locking ring 1430 Eyebolt
Figure12-69 Helical gearbox E, sizes 39 - 89
12.3.33.2 Helical gearbox D/Z, sizes19-89
Note
For gearbox sizes 19 and 29, we recommend that Siemens AG replaces the gearbox if service is
required.
Parts subject to wear are available on request.
Additional information on the SIMOGEAR geared motor
12.3Speci󹪝c data gearbox
SINAMICS G115D Wall Mounted distributed drive
566 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
