12.2.6 Fastening for suspended transport
WARNING
Motors may come loose during transport if not adequately secured
Do not use the integrally cast lifting eyes ① on the motor to transport the geared motors due
to the risk of breaking. Only use the integrally cast eyebolts ① to transport the motor prior to
mounting or following removal.
If necessary, use additional, suitable lifting accessories for transport or during installation.
When attaching by a number of chains and ropes just two strands must be sucient to bear the
entire load. Secure lifting equipment so that it cannot slip.
① Integrally cast eye on the motor
Figure12-5 Motor attached for suspended transport
12.2.7 Storage
WARNING
Injuries caused by falling objects
Danger of serious injuries caused by falling objects.
NOTICE
Failure of the exterior protection
Mechanical damage, chemical damage and thermal damage, such as scratches, acids, alkalis,
sparks, welding beads and heat cause corrosion.
Do not damage the paint nish.
Note
Danger of damage to the motor when stacked
Do not stack gearboxes or geared motors on top of each other.
Unless contractually agreed otherwise, the warranty period for the standard preservative
lasts 6months from the date of delivery.
Additional information on the SIMOGEAR geared motor
12.2Specic data motor
SINAMICS G115D Wall Mounted distributed drive
450 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
