Frame
size
Rated pow‐
er (kW)
Net weight (kg/lb.)
Glanded
variant
Glanded
variant with
Q8/0 or M12
Connector
variant
Additional weight
FSA 0.37 to 1.5 5.54 (12.19) 5.66 (12.44) 5.77 (12.70)
• Integrated repair switch:
+0.18 (0.4)
• Integrated LRC panel: +0.15
(0.33)
• Integrated 24V PSU:
+0.55(1.21)
FSB 2.2 to 3 7.12 (15.67) 7.24 (15.92) 7.35 (16.18)
4 7.52 (16.55) 7.64 (16.80) 7.74 (17.03)
FSC 5.5 to 7.5 7.85 (17.27) 7.97 (17.52) 8.08 (17.78)
Typical current consumption on 24VDC power supply
G115D
wall-moun‐
ted con‐
verter

Rated power Typical current consumption
from the 24V power supply, un‐
switched
1) 3)
Typical current consumption
from the AS-i cable
2) 3)
PROFINET var‐
iant
I/O variant AS-i variant
Yellow cable Black cable
FSA 0.37 kW to 1.5
kW
290mA 250mA 90mA 200mA
FSB 2.2 kW to 3 kW 290mA 250mA 90mA 200 mA
4 kW 550mA 510mA 90mA 460mA
FSC 5.5 kW to 7.5 kW 580mA 540mA 90mA 490mA
1)
The typical current consumption does not include the consumption of connected sensors at DI 0 to DI 3
from the unswitched 24 V power supply and the consumption of connected sensors/actors at DIO 24/
DIO25 from the switched 24V power supply.
2)
The typical current consumption does not include the consumption of connected sensors at DI 0 to DI 3
from the yellow cable and the consumption of connected sensors/actors at DIO 24/DIO25 from the
black cable.
3)
The current consumption for digital inputs DI 0 ~ DI 3 is max. 200 mA in total. The current consumption
for digital inputs DI 24 and DI 25 (when DIO 24/DIO 25 is con󹪝gured as DI) is max. 200 mA in total, and
the current consumption for digital outputs DO 24 and DO 25 (when DIO 24/DIO 25 is con󹪝gured as DO)
is max. 500mA in total.
Standby currents
G115D wall-mounted converter Standby current (mA)
Mains power supply without 24VDCpower supply
Frame size Rated power 380 V, 50 Hz 380 V, 60 Hz 400 V, 50 Hz 400 V, 60 Hz 480 V, 50 Hz 480 V, 60 Hz
FSA 0.37 kWto 1.5 kW 136 163 143 171 171 206
FSB 2.2 kWto 4 kW 172 207 181 217 217 261
FSC 5.5kWto7.5kW 255 306 268 322 321 386
Technical data
11.1Technical data of the G115D wall-mounted converter
SINAMICS G115D Wall Mounted distributed drive
414 Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA
