Frame size Terminal Cross-section for stranded conductor
FSC U/V/W/PE 4× 4mm
2
(AWG 12)
EM+/EM-, EM1/EM2 2×0.75mm
2
to4mm
2
(AWG 18toAWG 12)
T+/T- 2×0.75mm
2
to1.5mm
2
(AWG 18toAWG 16)
Glanded variant
Frame size Terminal Cable lug Cross-section for stran‐
ded conductor
Screw tighten‐
ing torque
Wall-mounted converter
FSA U/V/W Screw-type Fork-type 4×2.5mm
2
to4mm
2
(AWG 13 to AWG 12)
1.0Nm
(8.9lbf.in)
PE Ring-type 2.2Nm
(19.5lbf.in)
FSB U/V/W Screw-type Fork-type 4×2.5mm
2
to4mm
2
(AWG 13 to AWG 12)
1.0Nm
(8.9lbf.in)
PE Ring-type 2.2Nm
(19.5lbf.in)
FSC U/V/W Screw-type Fork-type 4×4mm
2
(AWG 12)
1.0Nm
(8.9lbf.in)
PE Ring-type 2.2Nm
(19.5lbf.in)
Frame size Terminal Cable lug Cross-section for stran‐
ded conductor
Crimping
length
Wall-mounted converter
FSA/FSB/FSC EM+/EM-,
EM1/EM2
Spring-type Pin-type 2×0.75mm
2
to4mm
2
(AWG 18toAWG 12)
12mm
T+/T- 2×0.75mm
2
to1.5mm
2
(AWG 18toAWG 16)
10mm
24VDC power supply terminals (2L+/2M/1L+/1M)
Connector variant
Frame size Cross-section for stranded conductor
FSA/FSB/FSC 4 × 0.75 mm
2
to 2.5 mm
2
(AWG 19 to AWG 13)
Glanded variant
Frame size Terminal
type
Cable lug Cross-section for stranded conductor Crimping
length
FSA/FSB/FSC Spring-type Pin type 4 × 0.75 mm
2
to 2.5 mm
2
(AWG 19 to
AWG 13)
10mm
Wiring
5.8Cables and connectors
SINAMICS G115D Wall Mounted distributed drive
Operating Instructions, 07/2023, FW V4.7 SP14, A5E52808211A AA 67
