Siemens SINUMERIK User Manual

Programming and Operating Manual (Turning)
58 01/2017
6.
Use this key or move the cursor to confirm your entries.
10.4
Setting R parameters
Functionality
The "R variables" start screen lists the R parameters that exist within the control system. You can set or query these global
parameters in any program as required.
Operating sequence
1.
Select the offset operating area.
2.
Open the list of R parameters.
3.
Press
the cursor keys to navigate in the list, and enter the values in the input fields to be
modified.
Note:
You can search for your desired R variable with this softkey. By default, the function
searches the R number.
You can press this softkey to activate the option of searching by R name. Define the R
name as desired, if necessary.
4.
Press this key or move the cursor to confirm your entries.
For more information about R parameters, see Section "Arithmetic parameter R (Page 124)".
10.5
Setting user data
Functionality
The "User data" start screen lists the user data that exist within the control system. You can set or query these global
parameters in any program as required.
Operating sequence
1.
Select the offset operating area.
2.
Open the list of user data.
3.
Use the cursor keys to navigate in the list, and enter the values in the input fields to be mo
d-
ified.
Note:
You can search for your desired user data with this softkey.
You can press this softkey to continue searching your desired user da
ta.
4.
Use this key or move the cursor to confir
m your entries.
