Siemens SINUMERIK User Manual

Programming and Operating Manual (Turning)
66 01/2017
10.7.3.2
Executing from external (through RS232 interface)
Prerequisites:
● The tool SinuComPCIN has been installed on your computer.
● The RS232 communication has been successfully established between the control system and the computer.
Proceed as follows to execute a part program from external through the RS232 interface:
1.
Select the program management operating area.
2.
Press this softkey to go to the RS232 directory.
3.
Press this vertical softkey, and the system automatically changes to "AUTO" mode in the
machining operating area.
4.
Press this button on the main screen of SinuComPCIN and select the desired pr
ogram for
execution, for example, Test.mpf. The program is transferred to the buffer memory on the
control system and then displayed in the following window:
5.
If desired, you can use this softkey to specify how you want the program to be executed (for
more information of the program control, refer to Section "
Program control functions
(Page
51)") .
6.
Press this key to execute the program. The program is reloaded continuously.
Either at the end of the program or after pressing the following key, the program is automa
t-
ically removed from the control
system:
Note
When using the external exec
ution via RS232, the RS232 interface must not be active for another application. This means,
for example, the RS232 interface must not be active t
hrough the following operation:
+ → →
