Programming and Operating Manual (Turning)
01/2017
63
Move the cursor to the following input fields:
: Enter the user name of your Windows account
: Enter the logon password (case sensitive) of your Windows account
: Enter the IP address of the server and the share name of the shared directory on your
computer. Example: //140.231.196.90/808D
Press this softkey to confirm and the configured networ
k drive appears on the screen as
follows. The drive icon is yellow if the network drive is connected su
ccessfully; otherwise,
You can delete a selected network drive using this softkey.
Note
After you properly configure all the settings for the direct connection between the control system and the network drive, if the
network dr
ive connection is still invalid, contact your Windows system administrator for possible problems with your
operating system configuration.
Executing from external (through Ethernet connection)
Prerequisites:
● An Ethernet connection has been established between the control system and the computer.
● A network drive (which includes the part program to be executed) has been created and connected.
Proceed as follows to execute a part program from external through the Ethernet connection:
t the program management operating area.
ss this softkey to view the network drive(s) created.
Select the desired network drive (which includes the part program to be executed) and
press this key to open it.
Select the program file you desire to execute.
