Programming and Operating Manual (Turning)
01/2017
79
11.2.3
Dimensions in metric units and inches: G71, G70, G710, G700
Functionality
If workpiece dimensions that deviate from the base system settings of the control system are present (inch or mm), the
dimensions can be entered directly in the program. The required conversion into the base system is performed by the control
system.
Programming
G70
; Inch dimensions
G71
; Metric dimensions
G700
; Inch dimensions, also for feedrate F
G710
; Metric dimensions, also for feedrate F
Programming example
N10 G70 X10 Z30
; Inch dimensions
N20 X40 Z50
;G70 continues to act
N80 G71 X19 Z17.3
; metric dimensioning from this point on
Information
Depending on the
default setting
you have chosen, the control system interprets all geometric values as either metric
or
inch dimensions. Tool offsets and settable work offsets including their displays are also to be understood as geometrical
values; this also applies to the feed F in mm/min or inch/min.
The default setting can be set in machine data.
All examples provided in this manual assume the
metric default setting.
G70 or G71 evaluates all geometrical data that directly refer to the
workpiece
, either as inches or metric units, for example:
Positional data X, Z, ... for G0,G1,G2,G3,G33, CIP, CT
Interpolation parameters I, K (also thread lead)
Circle radius CR
Programmable
work offset (TRANS, ATRANS)
All remaining geometric parameters that are not direct workpiece parameters, such as feedrates, tool offsets, and
settable
work offsets, are not affected by
G70/G71
.
G700/G710
,
however, also affects the feedrate F (inch/min, inch/rev. or mm/min, mm/rev.).
11.2.4
Radius/diameter dimensions: DIAMOF, DIAMON, DIAM90
Functionality
For machining parts, the positional data for the
X axis
(transverse axis) is programmed as diameter dimensioning. When
necessary, it is possible to switch to radius dimensioning in the program.
DIAMOF or DIAMON assesses the end point specification for the X axis as radius or diameter dimensioning. The actual
value appears in the display accordingly for the workpiece coordinate system.
For DIAM90, irrespective of the traversing method (G90/G91), the actual value of the transverse axis is always displayed as
a diameter. This also applies to reading of actual values in the workpiece coordinate system with MEAS, MEAW, $P_EP[x]
and $AA_IW[x].
Programming
DIAMOF
; Radius dimensioning
DIAMON
; Diameter dimensioning
DIAM90
; diameter dimensioning for G90, radius dimensioning for G91
